Features
♦ IP-67 Waterproof design
♦ 14.5 mm letters height on LCD Display (Optional devise - customer display)
♦ Weight Unit Setting: kg / 100g available
♦ With Single-interval or Multiple range Division
♦ Auto Zero-Point Tracking
♦ Environmental Filter Setting for better performance
♦ 3 Pre-set Memory Keys (M1~M3) for saving unit weight
♦ Counting operation by sample-quantity or unit weight setting
♦ Quantity alarm setting
♦ Weight checking function (High/Low limit setting)
♦ Low Power & Charging Status Indication
♦ Available to connect the external printer (optional RS-232 interface:
Argox (OS-203DT series) / Datecs (LP-50 series) / SPRT (SP-POS58 series)
Specifications
♦ Non-approval model: 1/6000 display resolution (single-interval or multiple range with 1/3000 upon request)
♦ Approval model: 1/3000 display resolution (single-interval or multiple range available)
♦ The capacity and devision shown as below are based on multiple range.
|
MODEL
|
Capacity
|
Division I
|
Division II
|
Division III
|
|
WDP-IN-60
|
60kg
|
20g
|
10g
|
5g
|
|
WDP-IN-150
|
150kg
|
50g
|
20g
|
10g
|
|
WDP-IN-300
|
300kg
|
100g
|
50g
|
20g
|
|
WDP-IN-600
|
600kg
|
200g
|
100g
|
50g
|
|
Display
|
6 digits Large LCD Display
|
|
Keyboard
|
20 keys tactile
|
|
Weighing Units
|
Kg / 100g
|
|
Stabilization
|
3 sec
|
|
Tare Range
|
50% of full scale capacity
|
|
Calibration
|
External calibration
|
|
Operating Environment
|
Temperature : -10 °C ~ 40 °C (14 °F ~ 104 °F)
Humidity: < 80%
|
|
Power Source
|
DC: 4Ah/6V Rechargeable Battery
(160 hours without Backlight)
AC: 110V or 220V ± 10%, 60Hz/50Hz
|
|
Overall Dimensions
|
239mm x 114mm x 101.5mm (WxDxH)
|
|
Packing
|
Shipping Carton: 6units/CTN; 4.9CUFT
N.W.: 15.40kg / G.W.: 20.66kg
|
♦ Place of Origin: MADE IN CHINA
